- LiuGong 965EHD, with its class-leading low fuel consumption: Equipped with a Scania engine and a large displacement main pump of 280cc, it boasts high productivity and low fuel consumption in its class, making transportation efficient. Suitable for various applications such as loading, crushing, rock arm operations, and more.
- Heavy-duty Design: Tailored specifically for mining operations, it delivers exceptional efficiency in tasks like mine crushing, stone loading, shale hard cap breaking, coal stripping, earning trust through high output. Meticulously tuned for maximum fuel efficiency across industries, it promises the output of a 70-ton machine while consuming fuel equivalent to a 50-ton operation, offering an excellent return on investment.
- Scania DC13 Engine: Adopting an advanced design philosophy of ‘maintenance during operation’, it incorporates sophisticated combustion control technologies for strong transient response, efficient power delivery, and unparalleled fuel economy. Its unique cylinder liner technology ensures the pistons operate efficiently with reduced carbon buildup, enhancing engine reliability.
- Positive Flow Hydraulic System: The machine features a 280cc large displacement electronically controlled main pump paired with a 700B large bore valve block. Coupled with LiuGong’s proprietary IPC control technology, it ensures precise matching, swift operation, and low fuel consumption.
- Hammer Operation without Overheating: With a large area radiator and a fan system utilizing variable speed smart control technology, it maintains low temperature and fuel consumption under low loads, while high temperatures trigger high-speed, efficient cooling, keeping hydraulic oil and water temperatures within an optimal range.
- Hammer Technology Innovation: Selecting the right working mode enhances efficiency. Mode B is specifically designed for crushing operations, matching the appropriate power output to make hammering tasks effortless. The intelligent reminder function promotes standardized operation, further enhancing usability and performance.
965EHD
Operating Weight:
60000 kg
Rated Power:
331kW
Bucket Capacity:
4.1 m3
965EHD
Product Features
965EHD
Specifications
| Operating Weight | 60000 kg |
| Power | 331kW |
| Bucket Capacity (Standard) | 4.1 m3 |
| Engine Model | Scania DC13 |
| Emission Standard | CN III |
| Configuration | 6-cylinder inline, turbocharged, air-to-air intercooler, electronically controlled direct injection |
| Rated Power (at Rated Speed) | 331kW |
| Max. Torque (Torque/Speed) | 2,007 N.m @1,600 rpm |
| Cooling System | Water-cooled |
| Swing Speed | 8.7 rpm |
| Gradeability | 35 ° |
| Ground Pressure | 95.3 kPa |
| Max. Digging Force - Stick (ISO) | 300/285/285 kN |
| Max. Digging Force - Bucket (ISO) | 345/345/345 kN |
| Shipping length | 11870 mm |
| Shipping width | 3340 mm |
| Shipping height | 3385 mm |
| Track shoe width (std) | 600 mm |
| Boom | 6500 mm |
| Arm | 2550 mm |
| Digging reach | 11020 mm |
| Digging reach on ground | 10780 mm |
| Digging depth | 6830 mm |
| Vertical wall digging depth | 4360 mm |
| Cutting height | 10190 mm |
| Dumping height | 6840 mm |
| Minimum front swing radius | 4880 mm |
| System maximum flow | 2x448 L/min (2x118 gal/min) |
| System pressure | 35 MPa |
