- The QSL engine, exclusively built by Cummins for LiuGong excavators, has staged combustion to control combustion temperature and pressure, which greatly improves energy conversion efficiency.
- According to the operating characteristics of the excavator, avoid high fuel consumption areas and match the hydraulic system, fuel consumption reduced by 15%.
- Oil bath pre-filter, suitable for mining dust harsh working conditions.
- The industry 's largest cab with standard sun visors, sun shades on both sides, 10 vents, providing luxurious driving experience.
943EMH
Operating Weight:
43,500 kg
Rated Power:
169 kw@ 2,050 rpm
Bucket Capacity:
1(Plum grab)
943EMH
Product Features
943EMH
943EMH
943EMH
943EMH
Specifications
| Operating weight | 43,500 kg |
| Rated power | 169 kw@ 2,050 rpm |
| Standard bucket capacity | 1(Plum grab) |
| Bucket capacity | 1.5、2.5、3.5m3(Shell bucket)、2m3(Log grab)、Electromagnetic chuck |
| Travel speed (high/low) | 5.3/3.1 km/h |
| Swing speed | 9.2 r/min |
| Shipping length | 12,650 mm |
| Shipping width | 4,342 mm |
| Shipping height | 3,175 mm |
| Shoe width | 600 mm |
| Gradeability | 35° |
| Ground pressure | 73.3 kPa |
| Max. grabbing reach | 14,200 mm |
| Max. grabbing reach on ground | 14,000 mm |
| Max. grabbing depth | 6,050 mm |
| Max. grabbing height | 15,600 mm |
| Engine | Cummins QSB7 |
| Emission regulation | Stage ⅢA/CN III |
| Main pumps total flow | 2x300 L/min |
| Relif Pressure, Main | 34.3 MPa |
