936E

Proven negative flow hydraulics have optimized the main control valve, improved the speed of front end cylinders, while cutting down the hydraulic system’s damper loss, leading to much better working efficiency.
Fuel efficient Cummins engine comes with a combination of a proven cooled-EGR system.
The LiuGong E series excavator features 6 selectable working modes that optimize performance and fuel consumption to your specific conditions
E series cab high-strength ROPS ensures operator protection. Falling Object Protection System (FOPS) is optional.

936E

936E－Stage II

Compare product

Operating weight	35,000-37,000 kg	77,162-81,571 lbs
Engine power	241 kW (323 hp) @ 2000 rpm	241 kW (323 hp) @ 2000 rpm
Std. Bucket capacity	1.6 m3	2.09 yd3
Travel speed(High)	5.5 km/h	3 mph
Maximum travel speed (Low)	3.4 km/h	2 mph
Maximum swing speed	10 rpm	10 rpm
Arm breakout force	170 kN	38218 lbf
Arm breakout force Power boost	185 kN	41590 lbf
Bucket breakout force	232 kN	52156 lbf
Bucket breakout force Power boost	252 kN	56652 lbf
Shipping length	11167 mm	36’8”
Shipping width	3190 mm	10’6”
Shipping height	3530 mm	11’7”
Track shoe width (std)	600 mm	1’12”
Boom	6400 mm	20’12”
Arm	3200 mm	10’6”
Digging reach	11100 mm	36’5”
Digging reach on ground	10900 mm	35’9”
Digging depth	7340 mm	24’1”
Vertical wall digging depth	6460 mm	21’2”
Cutting height	10240 mm	33’7”
Dumping height	7160 mm	23’6”
Minimum front swing radius	4465 mm	14’8”
Model	Cummins 6LTAA8.9-C325	Cummins 6LTAA8.9-C325
Emission	Stage II	Stage II
System maximum flow	2×300 L/min (2x79 gal/min)	2×300 L/min (2x79 gal/min)
System pressure	34.3 MPa	4975 psi
Download Brochure

936E－Stage IIIA

Compare product

Operating weight	35000 kg	77162 lbs
Engine power	214 kW (287 hp) @ 2000 rpm	214 kW (287 hp) @ 2000 rpm
Std. Bucket capacity	1.6 m3	2.09 yd3
Travel speed(High)	5.5 km/h	3 mph
Maximum travel speed (Low)	3.4 km/h	2 mph
Maximum swing speed	10 rpm	10 rpm
Arm breakout force	170 kN	38218 lbf
Arm breakout force Power boost	185 kN	41590 lbf
Bucket breakout force	232 kN	52156 lbf
Bucket breakout force Power boost	252 kN	56652 lbf
Shipping length	11167 mm	36’8”
Shipping width	3190 mm	10’6”
Shipping height	3530 mm	11’7”
Track shoe width (std)	600 mm	1’12”
Boom	6400 mm	20’12”
Arm	3200 mm	10’6”
Digging reach	11100 mm	36’5”
Digging reach on ground	10900 mm	35’9”
Digging depth	7340 mm	24’1”
Vertical wall digging depth	6460 mm	21’2”
Cutting height	10240 mm	33’7”
Dumping height	7160 mm	23’6”
Minimum front swing radius	4465 mm	14’8”
Model	Cummins L9PLUS	Cummins L9PLUS
Emission	EU Stage III/ CN III	EU Stage III/ CN III
System maximum flow	2×300 L/min (2x79 gal/min)	2×300 L/min (2x79 gal/min)
System pressure	34.3 MPa	4975 psi
Download Brochure

936E－Stage II LONG REACH ARM

Compare product

936E－Stage IIIA / Tier 3 LONG REACH ARM

Compare product
