- Cummins ' latest generation Euro V engine has better fuel economy
- The low-speed and high-torque engine is matched with a large-displacement main pump and a large-torque swing motor to ensure the performance of the machine while improving fuel economy
- The engine meets European EU StageV and North American EPA Tier4(f) emission regulations.
- For the first time, the Cummins engine adopts a global design without EGR, which reduces fuel consumption to a minimum while meeting the emission requirements of almost all regions of the world.
- The compact body design, with a minimum turning radius of only 1.52m, enables it to move forward and backward freely in cities, forests, and demolition conditions, protecting itself and the safety of surrounding personnel.
915FCR
Operating Weight:
15,700-17,500 kg
Rated Power:
90 kW
Bucket Capacity:
0.55 m3
915FCR
Product Features
915FCR
915FCR
915FCR
915FCR
Specifications
| Operating weight | 15700-17500 kg |
| Engine power | 90 kW @ 2200 rpm |
| Std. Bucket capacity | 0.55 m3 |
| Travel speed(High) | 4.9 km/h |
| Travel speed(Low) | 2.9 km/h |
| Maximum swing speed | 11.3 rpm |
| Arm breakout force | 70 kN |
| Bucket breakout force | 96.9 kN |
| Shipping length | 7335 mm |
| Shipping width | 2490 mm |
| Shipping height | 3050 mm |
| Track shoe width (std) | 500 mm |
| Boom | 4600 mm |
| Arm | 2500 mm |
| Digging reach | 8365 mm |
| Digging reach on ground | 8240 mm |
| Digging depth | 5540 mm |
| Vertical wall digging depth | 5055 mm |
| Cutting height | 9015 mm |
| Dumping height | 6485 mm |
| Minimum front swing radius | 2325 mm |
| Dozer-up | 540 mm |
| Dozer-down | 540 mm |
| Model | Cummins F3.8 |
| Emission | Stage V / Tier4F |
| System maximum flow | 2x117 L/min |
| System pressure | 34.3 MPa |
