- Cummins ' latest generation EU Stage V or Stage III engine has better fuel economy
- The low-speed and high-torque engine is matched with a large-displacement main pump and a large-torque swing motor to ensure the performance of the machine while improving fuel economy
- For the first time, the Cummins engine adopts a global design without EGR, which reduces fuel consumption to a minimum while meeting the emission requirements of almost all regions of the world.
- The compact body design, with a minimum turning radius of only 1.52m, enables it to move forward and backward freely in cities, forests, and demolition conditions, protecting itself and the safety of surrounding personnel.
913FCR
Operating Weight:
14,900-16,400 kg
Rated Power:
75 kW
Bucket Capacity:
0.5 m3
913FCR
Product Features
題-1.png)
913FCR
913FCR
913FCR
Specifications
| Operating weight | 14900-16400 kg |
| Engine power | 75 kW @ 2200 rpm |
| Std. Bucket capacity | 0.5 m3 |
| Travel speed(High) | 4.9 km/h |
| Travel speed(Low) | 2.9 km/h |
| Maximum swing speed | 11.3 rpm |
| Arm breakout force | 70 kN |
| Bucket breakout force | 96.9 kN |
| Shipping length | 7295 mm |
| Shipping width | 2570 mm |
| Shipping height | 3035 mm |
| Track shoe width (std) | 500 mm |
| Boom | 4600 mm |
| Arm | 2500 mm |
| Digging reach | 8315 mm |
| Digging reach on ground | 8190 mm |
| Digging depth | 5490 mm |
| Vertical wall digging depth | 5030 mm |
| Cutting height | 8960 mm |
| Dumping height | 6530 mm |
| Minimum front swing radius | 2325 mm |
| Dozer-up | 500 mm |
| Dozer-down | 575 mm |
| Engine model | Cummins F3.8 |
| Emission | Stage V / Tier4F |
| System maximum flow | 2x117 L/min |
| System pressure | 34.3 MPa |
| Download Brochure |
| Operating weight | 14,600 kg |
| Engine power | 86 kW |
| Std. Bucket capacity | 0.5 m3 |
| Travel speed(High) | 5.2 km/h |
| Maximum swing speed | 11.3 rpm |
| Arm breakout force | 70 kN |
| Bucket breakout force | 96.9 kN |
| Shipping length | 7295 mm |
| Shipping width | 2570 mm |
| Shipping height | 3035 mm |
| Track shoe width (std) | 500 mm |
| Boom length | 4600 mm |
| Arm length | 2500 mm |
| Digging reach | 8,315 mm |
| Digging reach on ground | 8,190 mm |
| Digging depth | 5,490 mm |
| Vertical wall digging depth | 5,030 mm |
| Cutting height | 8,960 mm |
| Dumping height | 6,530 mm |
| Minimum front swing radius | 2,325 mm |
| Dozer-up | 500 mm |
| Dozer-down | 575 mm |
| Engine model | Cummins QSF3.8 |
| Emission | Stage III |
| System maximum flow | 2x117 L/min |
| System pressure | 34.3 MPa |
