- Z-bar linkage with large transmission ratio uses high pressure hydraulics for increased breakout force.
- Heavy-duty wet type brake axle and braking system ensure the reliability and durability of the product even under tough work conditions.
- Fully-sealing and micro-pressuring system ensures the cab is clean and quiet. Silicone oil shock absorber reduces vibration and improves ride comfort.
- Improved ergonomics for cab design with all control switches in easy reach of the operator.
877H
Operating weight:
23,974 - 25,170 kg
Rated power:
205 / 213 kW
Rated load capacity:
7,000 kg
877H
Product Features
877H
877H
877H
877H
Specifications
| Operating weight | 23,974 kg |
| Standard bucket | 4.2 m3 |
| Rated power | 205 kW (275 hp / 279 ps) @ 2,000 rpm |
| Maximum gross power | 220 kW (295 hp / 299 ps) @ 2.000 rpm |
| Rated load capacity | 7,000 kg |
| Hydraulic cycle time | 10.3 s |
| Raise time | 5.7 s |
| Maximum travel speed | 38.3 km/h |
| Tipping load-full turn | 16,765 kg |
| Bucket breakout force | 203 kN |
| Dump clearance, full height discharge | 3,151 mm |
| Dump reach, full height discharge | 1,309 mm |
| Model | Cummins 6LTAA8.9 |
| Emissions | EPA Tier 2 / EU Stage II |
| Aspiration | Turbocharged & air-to-air intercooled |
| Length with bucket down | 9,150 mm |
| Width over tires | 2,970 mm |
| Cab height | 3,580 mm |
| Turning radius, outside of tire | 6,625 mm |
| Bucket capacity | 4.2-8.0 m3 |
| General Purpose bucket | 4.2 m3 |
| Light material bucket | 6.0, 7.0, 8.0 m3 |
| Rock bucket | 3.5, 4.2 m3 |
| Download Brochure |
| Operating weight | 25,170 kg |
| Standard bucket | 4.2 m3 |
| Rated power | 213 kW (286 hp / 290 ps) @ 2,000 rpm |
| Maximum gross power | 233 kW (312 hp / 317 ps) @ 2,000 rpm |
| Rated load capacity | 7,000 kg |
| Hydraulic cycle time | 10.6 s |
| Raise time | 5.8 s |
| Maximum travel speed | 40 km/h |
| Tipping load-full turn | 17,255 kg |
| Bucket breakout force | 203 kN |
| Dump clearance, full height discharge | 3,151 mm |
| Dump reach, full height discharge | 1,309 mm |
| Model | Cummins L9 |
| Emissions | EU Stage V |
| Aspiration | Turbocharged & air-to-air intercooled |
| Length with bucket down | 9,150 mm |
| Width over tires | 2,970 mm |
| Cab height | 3,580 mm |
| Turning radius, outside of tire | 6,625 mm |
| Bucket capacity | 4.2-8.0 m3 |
| General Purpose bucket | 4.2 m3 |
| Light material bucket | 6.0, 7.0, 8.0 m3 |
| Rock bucket | 3.5, 4.2 m3 |
