6032E

LiuGong’s high frequency and low amplitude vibration technology delivers consistent and high quality compaction and by avoiding unnecessary passes
Performance can be further enhanced by opting for the high frequency version of the 6032E. This powerhouse achieves 7.2 km/h which is a staggering 30% higher than traditional versions
Wide opening engine hood gives fast and easy access to the engine and service points

6032E

6032E－6032E

Compare product

Operating Mass	3360 kg	7408 lb
Mass On Front Drum	1620 kg	3571 lb
Mass On Rear Axle	1740 kg	3836 lb
Front Drum Static Linear Load	135 N/cm	12 lbf/inch
Rear Drum Static Linear Load	145 N/cm	13 lbf/inch
Model	Perkins 403D-15T	Perkins 403D-15T
Emission Regulation	Stage III	Stage III
Rated Power	27.3 kW (37 hp) @ 2600 rpm	27.3 kW (37 hp) @ 2600 rpm
Vibration Frequency	60 Hz	60 Hz
Nominal Amplitude	0.45 mm
Centrifugal Force	33.5 kN	7531 lbf
Drum Diameter	750 mm	2’6”
Drum Width	1200 mm	3’11”
N Maximum Speed fwd	10 km/h	6 mph
Theoretical Gradeability	30%	30%
Min. Ground Clearance	265 mm	10”
Wheelbase	1860 mm	6’1”
Min. Outside Turning Radius	4050 mm	13’3”
Overall Length	2610 mm	8’7”
Overall Width	1310 mm	4’4”
Overall Height	2645 mm	8’8”

6032E－6032E Combi

Compare product

Operating Mass	3200 kg	7055 lb
Mass On Front Drum	1650 kg	3638 lb
Mass On Rear Axle	1550 kg	3417 lb
Front Drum Static Linear Load	135 N/cm	12 lbf/inch
Rear Drum Static Linear Load	131 N/cm	12 lbf/inch
Model	Perkins 403D-15T	Perkins 403D-15T
Emission Regulation	Stage III	Stage III
Rated Power	27.3 kW (37 hp) @ 2600 rpm	27.3 kW (37 hp) @ 2600 rpm
Vibration Frequency	60 Hz	60 Hz
Nominal Amplitude	0.45 mm
Centrifugal Force	33.5 kN	7531 lbf
Drum Diameter	750 mm	2’6”
Drum Width	1200 mm	3’11”
N Maximum Speed fwd	10 km/h	6 mph
Theoretical Gradeability	30	30
Min. Ground Clearance	265 mm	10”
Wheelbase	1860 mm	6’1”
Min. Outside Turning Radius	4050 mm	13’3”
Overall Length	2610 mm	8’7”
Overall Width	1310 mm	4’4”
Overall Height	2645 mm	8’8”
